The CS09-DS is a robust asymmetric composite rod seal featuring a low-friction PTFE gliding element and an elastic energizer. Specifically designed for heavy-duty applications and pressure intensifiers, it includes integrated radial grooves that ensure rapid pressure activation. With a pressure rating up to 600 bar and a massive profile that resists wear and gap extrusion, the CS09-DS eliminates stick-slip and ensures exact positioning. It performs exceptionally well in large-diameter cylinders and remains non-sensitive to thermal damage, providing high mechanical efficiency for both slow and quick movements.
• Fast Pressure Activation: Integrated radial grooves ensure immediate sealing response.
• High Pressure Stability: Capable of handling up to 600 bar in heavy-duty environments.
• Zero Stick-Slip: PTFE material ensures smooth operation and precise positioning.
• Anti-Extrusion Design: Optimized chamfer and massive profile reduce the risk of gap extrusion.
• Versatile Hole Crossing: Specifically designed to safely run over appropriately chamfered ports.
• Heavy-Duty Build: Preferred for pressure intensifiers, control elements, and large cylinders.
Qingdao Carlock Sealing Tech is a premier manufacturer of high-precision CNC machined seals, specializing in "Big Brand Alternatives" with a 24-hour turnaround. We excel in producing complex composite profiles like the CS09-DS, utilizing premium PTFE, FKM, and NBR materials to meet international heavy-duty standards. Our no-mold-cost manufacturing process allows for rapid customization of standard and ultra-large diameter seals up to 2000mm. With deep technical expertise in high-pressure hydraulic systems, Qingdao Carlock provides global clients with cost-effective, durable, and high-performance sealing solutions that ensure maximum efficiency in the most demanding industrial applications.
