The CS02-PD is a specialized version of our asymmetric rod seal, specifically engineered for applications with limited installation space. Featuring a unique conical or triangular cross-section backup ring, it fits seamlessly into narrower grooves compared to the standard CS02-P profile. This compact design maintains exceptional anti-extrusion properties at pressures up to 700 bar while reducing the overall seal height. Available in HPU, FKM, and other premium materials, it provides superior static and dynamic sealing for precision hydraulic systems where space efficiency is critical.
• Narrow Groove Optimization: Designed specifically for compact and space-limited seal housings.
• Conical/Triangular Backup Ring: Innovative cross-section profile for enhanced extrusion resistance.
• Reduced Seal Height: Ideal for high-pressure systems requiring minimal axial space.
• 700 Bar Pressure Stability: Reliable sealing under extreme pressure and long-stroke conditions.
• Low Friction & Stick-Slip: Engineered for smooth movement and minimal break-away force.
• Multi-Material Precision: Machined from HPU, NBR, or FKM to match your media requirements.
1. CS02-PD-Compact-Rod-Seal-Profile 2. Conical-Backup-Ring-Sealing-Detail 3. CS02-PD-Narrow-Groove-Hydraulic-Seal 4. High-Pressure-HPU-Seal-for-Compact-Housings 5. Machined-Triangular-Backup-Ring-Structure 6. Space-Saving-Asymmetric-Rod-Lip-Seal 7. Custom-CS02-PD-Sealing-Solution-Carlock
Qingdao Carlock Sealing Tech specializes in high-precision CNC machined seals, providing high-performance "Big Brand Alternatives" with a 24-hour lead time. We excel at solving complex sealing challenges, offering custom designs for unique profiles like the CS02-PD. Our advanced machining process eliminates the need for expensive tooling, allowing us to produce both standard and ultra-large diameter seals up to 2000mm. With a focus on cost-effectiveness and technical expertise, Qingdao Carlock delivers reliable sealing solutions across diverse industries, from heavy-duty hydraulics to precision chemical processing, ensuring your equipment operates at peak efficiency.
